Erase

Delete things.

Keyboard: E

How to use it

  1. Click anything to delete it.
  2. Or hold the button down and drag over several - what the cursor gathers turns red, and none of it goes until you let go.
  3. Or select several and press Delete.
  4. Hold Ctrl and the eraser softens an edge instead of rubbing it out: the edge stops being drawn but the faces either side stay joined. Ctrl+Shift brings a softened edge back.
  5. With Ctrl held the eraser takes only edges, so there is no way to lose a face by aiming badly.
Two edges erased from the top of a box, and the lid goes with them, leaving an open box with its pale blue insides showing.
Two edges off the top of a box, and the lid goes with them. The pale blue is the back of the faces - you are looking at the inside of the box now, which is exactly what that color is for.

Edges and faces

A face is not a thing sitting there - it is what a closed run of edges encloses. So erasing an edge takes any face that was built on it, the way SketchUp does it: "faces are erased when you erase their bounding edges, opening and reshaping your geometry". Rub one edge off a box and the two sides meeting along it go with it, and you are looking into an open box.

To put one back, draw the line again along where it was. The faces come back with it, and a side traced back into a box rejoins the box rather than sitting loose on top of it. That is SketchUp's healing and it is the only way back to a face you meant to delete and then did not.

The eraser takes edges, and takes a face only by taking the edges that hold it up - which is SketchUp's arrangement: "The Eraser tool doesn't allow you to erase faces." Click a bare face with it and nothing goes; the bar along the bottom says so.

To remove a face on its own, right-click it and choose Erase, or pick it with the select tool and press Delete. Both leave every edge standing, so what you get is an open box with a complete wireframe lid. Undo brings anything back.

A face in a group is the group's: erasing an edge takes only the faces of its own group. Erasing stairs whose board lies along the top of a wall leaves the wall's face alone.

Guides

The eraser leaves guides alone - a swipe across a drawing never takes a guide point or a dashed guide line. Guides are the tape's to erase: with the tape in hand, right-click the guide (see erasing a guide).
